Kitchen Cabinet Layout and Installation Help

Need help laying out your new kitchen?

Here are our best recommendations for
designing your new kitchen.

PRINT THESE FORMS to help you layout the perfect kitchen!

HINT: Set your printer to Landscape with No Margins.

Kitchen Layout Instruction Sheet Print Kitchen Layout Instruction Page

Sample Kitchen Layout Sheet Sample Kitchen Layout Page

Blank Kitchen Layout SheetBlank Kitchen Layout Page

Kitchen Layouts Explained 5 Typical Kitchen Layouts

How To Install Kitchen Cabinets

  1. level and pencilUse a level and a pencil to draw a perfectly parallel line across the wall about 3 inches up from the floor. Measure down from this line to the floor to find the floor's hight point (if it has one), and mark a line at that point. From there, measure up 34 1/2 inches and draw a level line across the wall to designate the top of the base cabinets.
  2.

  3. draw a lineFrom the 34 1/2 inch line, measure up another 19 1/2 inches and mark a level line across the wall to indicate the bottom of the wall cabinets. Lightly mark the cabinets' dimensions and placement to double-check your layout.
  4.

  5. use a stud finderUse a stud finder to locate the wall studs, then, with a pencil, mark their locations above and at least 6 inches below the mark you've made for the bottom of the wall cabinets. Draw straight vertical lines between the top and bottom marks to indicate the center of the studs.
  6.

  7. temporary supportScrew a temporary 1-by-3 support rail to the wall, aligning the top edge of the rail with the line for the bottom edge of the wall cabinets. Attach it by driving three or four 2-inch screws through the rail into the wall studs.
  8.

  9. corner wallInstall the corner wall cabinet first, with a helper. Drill pilot holes through the sturdy cabinet back or it's support rail and into the wall studs. Screw the cabinet to the wall using two screws that are long enough to penetrate the studs by at least 1 1/2 inches, then check the top for level and the front edge for plumb. To correct the position, back off the screws, tap shims behind the cabinet at stud locations, then drive the screws home and add several more into each stud for secure attachment.
  10.

  11. Install the adjacent cabinets. As you install each one, secure it to its neighbor with a clamp and check it for plumb. On face-frame cabinets, it's easiest to drill two 1/5-inch pilot holes through the sides of the face-frame and use screws,
    With frameless cabinets, drill bolt holes through shelf-peg holes, then bolt the two together. Be sure not to fasten through shelf-peg holes that you will need for shelves.
  12.

  13. install the cornerAfter all the wall cabinets are in place, install the corner or end base cabinet. If necessary, use shims to level it and raise it up to the high point of the floor, so its upper edge aligns with the line on the wall. Be sure it is level from front to back and from side to side, then screw in the wall studs.
  14.

  15. turn a cornerTo turn a corner with base cabinets, push the adjoining cabinet in pace and clamp the two units together. Add a filler strip is needed to the doors and drawers clearance. If necessary, tap shims under the cabinet and behind it to adjust for plump and level.
  16.

  17. drive screwsDrive screws through the cabinet back (and shims) into the wall studs. Trim any excess materials from the shims with a sharp chisel or knife. Continue to add adjoining cabinets in the manner, joining them as you did the wall cabinets in step 6.

clamp

Copyright Sunset Publishing Corporation, 2003
